When you are done, show your work to the TAs in Violet UML, which should look just like the images provided.Online diagram and flowchart software that supports Microsoft Visio import. But today’s exercise will give you a good idea of what the code may eventually look like, based on your design. One thing to note is that the software development process will usually be the reverse of what you are doing in today’s recitation, i.e., you first design and then code. UML sequence diagram (for pausing) (./Recitation6PauseSequenceDiagram.png) UML sequence diagram (for starting) (./Recitation6StartSequenceDiagram.png) UML class diagram (./Recitation6ClassDiagram.png) Your Violet UML model diagrams should look like these when you are done. Note that three images have been provided. One for each button response, meaning what sequence of method calls results when each event is generated. Then, generate two UML sequence Diagrams. Open it, run it, and examine the code.įirst generate a UML Class Diagram that represents the code provided in the project.
#Violet uml editor sequence diagram download#
Next, download this NetBeans project (./Recitation6.zip). In this assignment, you will create two diagrams: (i) a UML class diagram, and (ii) a UML sequence diagram. For software design, the most commonly used types are UML class diagrams, which define class structures and relationships, and UML sequence diagrams, which define behavior.įirst, download the VioletUML Editor (version 2.1.0) to some location where you can find it. for software specifications (SRS) documents). There are a number of different types of UML diagrams, including UML Use Case diagrams, which are used for developing requirements, i.e. The idea is that by designing a software system before building it, one can create more modular, flexible, and maintainable high quality work. The Unified Modeling Language (UML) is a standard means for representing object- oriented designs. In this recitation you will create two type of UML diagrams: class diagrams and sequence diagrams. Notify your Recitation TA once you have completed this recitation such that they may verify your work.
